PSC Series Double Suction Split Case Pump

Short Description:

Introducing the PSC Series Double Suction Split Pumps – a versatile and reliable solution for your pumping needs.

The pump is designed with advanced features to ensure optimum performance and durability. The volute pump casing is removable for easy maintenance and inspection. The pump casing is coated with HT250 anti-corrosion coating, which makes it suitable for harsh environments and ensures its long-lasting performance.

Flow range: Lift range

100~3000m³/h: 10~200m

Send email to us

Product Detail

Product Tags

Product Introduction

The PSC series is equipped with double radial impellers in AISI304 or HT250. This impeller design ensures efficient fluid movement, providing excellent flow rates. It also features a shaft protector seal for an extra layer of safety against leaks.

This pump can be customized to meet your specific requirements by choosing a mechanical or packing seal. Both options are designed to provide reliable sealing performance for trouble-free operation. The pump uses high quality greased rolling bearings with long seal life, further enhancing its reliability and minimizing maintenance needs.

In addition, the PSC series double suction split case pumps are extremely versatile. It can be easily equipped with an electric motor or a diesel engine, making it suitable for a variety of applications, including fire protection systems.

In terms of structural features, the pump is designed to withstand harsh conditions. It can handle liquid temperatures from -10°C to 120°C, making it suitable for a wide variety of fluids. The pump is also designed to operate in ambient temperatures from 0°C to 50°C, ensuring its performance even in extreme environments. With an operating pressure of 25 bar/continuous S1, the pump can easily handle high pressure applications.

In conclusion, the PSC Series double suction split pump is a reliable and versatile solution for your pumping needs. Its removable volute casing, anti-corrosion coating, choice of impeller material and sealing options make it a robust and customizable choice. Capable of being equipped with an electric motor or a diesel engine, and with its impressive temperature and pressure capabilities, the pump is a versatile and reliable choice for a variety of applications.
