PGWH Explosion proof horizontal single stage centrifugal pipeline pump

Short Description:

Introducing our latest innovation in pump technology – the PGWH horizontal stainless steel single stage centrifugal in-line pump. Developed by our experienced team with years of production expertise, this product is designed to revolutionize your pumping needs.

Send email to us

Product Detail

Product Tags

One of the key features of this pump is its stainless steel construction. This material has enhanced corrosion resistance, ensuring the pump will perform at its best even in the harshest environments. Additionally, the stainless steel body improves wear resistance and reduces the need for frequent parts replacement, saving costs in the long run.

The flow range of this series of products is 3-1200m/h, and the water supply efficiency is high, meeting the stringent requirements of various applications. Whether you need to deliver large volumes of water or maintain a steady flow, PGWH pumps can meet your requirements.

With a lifting range of 5 to 150m, this product range offers excellent versatility for a variety of projects. Additionally, we offer a wide range of product sizes, allowing you to choose the right pump for your specific needs. Whether you need a specific flow rate or lifting capacity, we have you covered.

In order to meet different application requirements, we have designed and manufactured two variants of this pump – PGL type hot water pump and PGH type stainless steel pipeline chemical pump. These variants are characterized by changes in the material and construction of the wetted part to accommodate different media and temperatures. This series of pumps is well received by customers and has the ability to completely replace the traditional centrifugal pumps commonly used in various industries.

In summary, the PGWH Horizontal Stainless Steel Single Stage Centrifugal In-Line Pump is a game changer in the pump industry. Its stainless steel construction, wide flow range and lifting capacity make it ideal for a variety of applications. Why pay less when you can have a pump that performs well and lasts? Upgrade to a PGWH pump and experience the difference.

working conditions

1.The pump system maximum pressure is 1.6MPa.that is to say the pump suction pressure + pump head <1.6MPa.(Please specify the system working pressure when) ordering, If pump system working pressure s greater than 1.6Ma,should be separately put forward when ordering, therefore we will use of steel materials to manufacture the over-current and connected parts of the pump.)
2.Medium:insoluble solids volume contents of no more than the volume per unit’s 0.1%. particle size less than 0.2mm.(f the medium contents of small particles, the wear-resistant mechanical seals is used.So please note it when ordering.)
3.The ambient temerature does not exceed 40′C, relative humidity is no more than 95%,altitude does not exceed 1000m.
4.PGLPGW Cod/Hot water centrifugal pumps is for conveying clean water or other liquids which physical properties are similar to water. Used in: energy. metallurgy, chemicals. textiles,paper.and hotels restaurants boiler and city heating system circulating pump.Medium temperature T≤100C.
5.PGLH/PGWH stainless steel centrifugal chemical pump is for conveying corrosive liquids that without solid particles.Medium temperature
-20C–~100C。
6.PGLB/PGWB explosion-proof centrifugal oil pump is for conveying petroleum products like gasoline,kerosene,diesel.Medium temperature
-20C–~100C。
